Upcoming machining facilities
LMW CNC TURNING
CNC VTL
- Karayampalayam, Mylampatti, Coimbatore 641 062
| Axis | Size |
|---|---|
| X | 1200 mm |
| Y | 1500 mm |
| Z | 1000 mm |
| Description | Specification |
|---|---|
| Work Table Size | 1400 x 610 mm |
| Axis Travel Distance | X1 - 1400 mm, Y1 - 610 mm, Z1 - 610 mm |
| Spindle Max RPM | 12000 RPM |
| Spindle Tapper | BT40 |
| Spindle Power | 7.5/18.5 KW |
| No. of Tools | 30NO's |
| Maximum Work Piece Weight | 1000 Kg |
| Controller | MAZATROL SmoothEz |
| Description | Specification |
|---|---|
| Work Table Size | 1200 x 600 mm |
| Axis Travel Distance | X1 - 1100 mm, Y1 - 600 mm, Z1 - 1050 mm |
| Spindle Max RPM | 6000 RPM |
| Spindle Tapper | BT40 |
| Spindle Power | 7.5 KW |
| No. of Tools | 24 |
| Maximum Work Piece Weight | 900 Kg |
| Controller | Fanuc (OI - MF PLUS) |
| Rotary Table 4th axis | 250 mm |
| Description | Specification |
|---|---|
| Work Table Size | 1200 x 550 mm |
| Axis Travel Distance | X1 - 1020 mm, Y1 - 600 mm, Z1 - 610 mm |
| Spindle Max RPM | 8000 RPM |
| Spindle Tapper | BT40 |
| Spindle Power | 14.3/11 KW |
| No. of Tools | 24NO’s |
| Maximum Work Piece Weight | 900 Kg |
| Controller | Siemens (Sinumerik 828D) |
| Rotary Table 4th axis | 250 mm |
| Description | Specification |
|---|---|
| Work Table Size | 1200 x 550 mm |
| Axis Travel Distance | X1 - 1000 mm, Y1 - 600 mm, Z1 - 600 mm |
| Spindle Max RPM | 8000 RPM |
| Spindle Tapper | BT40 |
| Spindle Power | 9/13 KW |
| No. of Tools | 24NO’s |
| Maximum Work Piece Weight | 800 Kg |
| Controller | Heidenhain TNC 430 |
| Description | Specification |
|---|---|
| Chuck Diameter | 385 mm |
| Maximum Turning Diameter | 550 mm |
| Maximum Turning Length | 2320 mm |
| Swing Over Bed | 745 mm |
| Spindle Power (Kw) | 18.5 KW |
| Maximum Spindle RPM | 1250 RPM |
| No. OF. Station | 12 No’s |
| Steady Rest Clamping Range | Ø45 to Ø310 mm |
| Controller | Fanuc (O1 - TF PLUS ) |
| Description | Specification |
|---|---|
| Chuck Diameter | 305 mm |
| Maximum Turning Diameter | 320 mm |
| Maximum Turning Length | 1020 mm |
| Swing Over Bed | 510 mm |
| Spindle Power (Kw) | 11/15 KW |
| Maximum Spindle RPM | 3500 RPM |
| No. OF. Station | 8 No’s |
| Steady Rest Clamping Range | Ø12 to Ø152 mm |
| Controller | Fanuc (O1 - TF) |
| Description | Specification |
|---|---|
| Control Type | CNC |
| Number of Axis | 2-Axis |
| Max. Turning Diameter | 480 mm |
| Max. Turning Length | 700 mm |
| Chuck Diameter | 300 mm |
| No. of Tools | 8 - Station |
| Description | Specification |
|---|---|
| Chuck Diameter | 250 mm |
| Maximum Turning Diameter | 360 mm |
| Maximum Turning Length | 515 mm |
| Swing Over Bed | 550 mm |
| Spindle Power (Kw) | 25 KVA |
| Maximum Spindle RPM | 3000 RPM |
| No. OF. Station | 8 No’s |
| Steady Rest Clamping Range | Ø12 to Ø152 mm |
| Controller | Fanuc (O1 - TF PLUS) |
| Description | Specification |
|---|---|
| Chuck Diameter | 250 mm |
| Maximum Turning Diameter | 290 mm |
| Maximum Turning Length | 500 mm |
| Swing Over Bed | 490 mm |
| Spindle Power (Kw) | 11 KW |
| Maximum Spindle RPM | 3500 RPM |
| No. OF. Station | 8 No’s |
| Controller | Fanuc (O1 - TF PLUS) |
| Description | Specification |
|---|---|
| Chuck Diameter | Ø200 mm |
| Maximum Grinding Diameter | Ø100 mm |
| Maximum Grinding length | 250 L |
| Function | Fully Automatic |
| Overall Table Working Area | Ø50 x 300 L |
| Description | Specification |
|---|---|
| Maximum Grinding Diameter | Ø400 mm |
| Maximum Grinding Length | 2500 mm |
| Wheel Speed | 1200 RPM |
| Grinding Wheel Size | 450 x 203.2 x 65 |
| Feed Angle | 45 Degree |
| Maximum Load | 500 Kg |
| Description | Specification |
|---|---|
| Chuck Diameter | Ø200 mm |
| Maximum Grinding Diameter | Ø100 mm |
| Maximum Grinding length | 250 L |
| Function | Fully Automatic |
| Over all Table Working Area | Ø50 x 300 L |
| Description | Specification |
|---|---|
| Maximum Grinding Diameter | Ø320 mm |
| Maximum Grinding Length | 1250 mm |
| Wheel Speed | 2400 RPM |
| Grinding Wheel Size | 300x40 |
| Feed Angle | 45 Degree |
| Maximum Load | 250 Kg |
| Control System | Fanuc (17i - TB) |
| Indexing | 1 Degree |
| Description | Specification |
|---|---|
| Model | MW9004 |
| Laser Power | 20W |
| Laser Source | MAX |
| Lens | F-Theta Lens |
| Laser Power | Taiwan MW Laser Power |
| Galvanometer | Sino Galvo |
| Working Area | 110 |
| Power Consumed | <800W |
| Minimum Line Width | 30μm |
| Minimum Character | 0.15mm |
| Laser Wavelength | 1064nm |
| Marking Depth | 0-0.5mm |
| Galvanometer Size | Repeatability Accuracy |
| Repeatability Accuracy | ±0.002mm |
| Control Software | EZCAD Control Software |
| Whole Machine Power | 300W |
| Cooling Way | Air Cooling |
| Operating Voltage | 110/220V ±10%, 50/60Hz |
| Engraving Speed | 0-7000mm/s |
| Machine Weight | 60KG |
| Dimensions | 350*600*550mm |
| Packing | Export Plywood Wooden Packaging |
| Packing Size | 780*450*470mm |
| Description | Specification |
|---|---|
| Drilling Capacity - Steel | 2.5" |
| Drilling Capacity - Cast Iron | 3" |
| Column Diameter | 16" |
| Quill Travel | 15" |
| Spindle Taper | 5 MT |
| Speeds (18) | 14-710 rpm |
| Feeds (4) | 70-180 cpi |
| Travel Saddle on Arm | 55" |
| Main Motor - 575/3/60 | 5 hp |
| Weight | 12,000 lbs |
| Description | Specification |
|---|---|
| Test Loads (Rockwell) | 60, 100, and 150 kgf |
| Test Loads (Rockwell Superficial - on select models) | 15, 30, and 45 kgf |
| Initial Minor Load | 10 kgf (Rockwell) / 3 kgf (Superficial) |
| Maximum Test Height | 220 mm to 300 mm |
| Depth of Throat | 132 mm to 155 mm |
| Resolution | 0.1 Rockwell unit via digital LCD display |
| Compliance Standards | Conforms to IS:1586:2000 (Rockwell/Superficial) and IS:2281:2005 (Brinell) |
| Description | Specification |
|---|---|
| Measuring Range | 1000 mm |
| Measuring Range with Extension | 1380 mm |
| Maximum Permissible Errors, BMPE | (2 + L / 330) µm (L is in mm) |
| Repeatability, RMPE (2s) | 0.001 mm on plane and 0.002 mm on bore |
| Frontal Squareness Deviation, SMPE | 6 µm |
| Maximal Resolution | 0.01, 0.001, 0.0005 mm |
| Measuring Force | 1.0N ± 0.2 |
| Autonomy | 16 h |
| Interfaces | USB/RS-232 |
| Air Cushion | Yes |
| Weight | 30 kg |
| Description | Specification |
|---|---|
| Measuring Range | 711 mm |
| Measuring Range with Extension | 1023 mm |
| Maximum Permissible Errors, BMPE | 2+L(mm)/400 µm |
| Repeatability, RMPE (2s) | 1(0.2) µm |
| Frontal Squareness Deviation, SMPE | 8 µm |
| Maximal Resolution | 0.0001 mm |
| Measuring Force | 0.75 ÷ 1.5 N |
| Autonomy | 12 h |
| Interfaces | USB / RS232 |
| Air Cushion | Yes |
| Weight | 25 Kg |
| Description | Specification |
|---|---|
| Z-axis Range | 14400 µm (-7900 µm ±6300 µm) (360 µm (-200 µm ±160 µm)) |
| Detector Range | 14400 µin / 8 µin (360 µm / 0.02 µm), 4000 µin / 2 µin (100 µm / 0.006 µm), 1000 µin / 0.8 µin (25 µm / 0.002 µm) |
| Measuring Speed |
0.01, 0.02, 0.03 in/s (0.25 mm/s, 0.5 mm/s, 0.75 mm/s) When Measuring: 0.04 in/s (1 mm/s) |
| Cut-off Length |
λc 0.003, 0.01, 0.03, 0.1 in (0.08, 0.25, 0.8, 2.5 mm) |
| Sampling Length |
0.003, 0.01, 0.03, 1 in (0.08, 0.25, 0.8, 2.5 mm) |
| Description | Specification |
|---|---|
| Z-axis Range |
14200 µm (-7900 µm ±6300 µm) (-200 µm ±160 µm) |
| Detector Range |
14170 µin / 8 µin (360 µm / 0.02 µm), 4000 µin / 2 µin (100 µm / 0.006 µm) |
| Measuring Speed |
0.01, 0.02, 0.03 in/s
(0.25 mm/s, 0.5 mm/s, 0.75 mm/s) Returning 1 mm/s |
| Cut-off Length |
λc 0.003, 0.01, 0.03, 0.1 in (0.08, 0.25, 0.8, 2.5 mm) |
| Sampling Length |
0.003, 0.01, 0.03, 1 in (0.08, 0.25, 0.8, 2.5 mm) |
| Description | Make | Specification |
|---|---|---|
| Vernier Caliper | Mitutoyo | 0 - 300 mm |
| Vernier Caliper | Mitutoyo | 0 - 1000 mm |
| Micrometer | Mitutoyo | 0 - 150 mm |
| Micrometer | Mitutoyo | 150 - 300 mm |
| Micrometer | Mitutoyo | 300 - 400 mm |
| Digital Height Gauge | Kency | 0 - 600 mm |
| Bore Gauge | Mitutoyo | 50 - 150 mm |
| Bore Gauge | Mitutoyo | 160 - 250 mm |
| Bore Gauge | Mitutoyo | 250 - 400 mm |
